*All axles are fixed price regardless of length.
*Most axles are kept in stock at our South Australian warehouse. Please allow 2-3 business days to have them delivered to one of our retails stores. Uncommon axle lengths may require machining (4-10 days).
Call us on 0412 836 296 or Contact Us.
$999.95
Adelaide Trailer Shop offers a wide range of Trailer Axle – 63mm Square (Natural).
We pride ourselves on supplying quality parts that we know and trust on our own trailers.
Our friendly staff can assist you with all your trailer needs.
Call us today on 0412 836 296 or Contact Us – See Locations.
63mm square trailer axles are generally used on tandem axle trailers (4500kg).
DIAMETER: 63mm square
RATING: 3000kg PER AXLE
STEEL: SOLID DURAFLEX STEEL
BEARING TYPE: F TYPE (3 TONNE)
A 1 1/4″ CASTLE NUT
B 38.1mm
C 50mm
D 60.3mm
BEARING CODES
SMALL BEARING:LM29749
LARGE BEARING:30210JR
SMALL CUP:LM29710
LARGE CUP:30210J
SET SKU:MLMF
When ordering a replacement trailer axle, we will need to know the overall length (tip to tip) or the hub face to hub face measurement.
It is important to ensure these measurements are correct as the slightest change in axle length can cause wheels to rub on your chassis or guards.
When ordering an axle for a new trailer build you will need to know several things:
What is the trailers chassis width
What wheels will I be using and what is their back space
What axle rating will I require
A:STUB MEASUREMENT – The measurement from the face of the hub to the tip of the axle. Each axle rating has a different stub measurement (see below).
B:WHEEL BACKSPACE – The measurement from the face of the hub to the rear tyre bulge (see below).
C:WHEEL GAP – The measurement of the space between the tyre bulge and the trailer chassis.
D:CHASSSIS – The measurement of the trailer chassis on the outer most points.
AXLE LENGTH = A B C D E F G
STUB TIP MEASUREMENTS (FROM HUB FACE)
A & B TYPE AXLES 110mm (55mm EACH SIDE)
PARALLEL 114mm (57mm EACH SIDE)
2 TONNE 160mm (80mm EACH SIDE)
3 TONNE 170mm (85mm EACH SIDE)
WHEEL BACK SPACE
To measure your wheels backspace, place the wheel on the ground face up.
Then measure from the ground to where the wheel meets the hub face. (mm)
This is to ensure the wheel wont rub on the trailer chassis.
*THIS IS TO BE USED AS A GUIDE ONLY AS DIFFERENT MANUFACTURERS CAN USE DIFFERENT OFF-SETS
It is important to us that our products meet your needs. We know this includes your financial needs. For this reason, we offer a range of discounts. First, we offer ‘bulk buy’ discounts. Second, for customers with an ABN, we offer trade discounts. Finally, we have discounts available to trailer manufacturers. Feel free to call us on 0412 836 296 or, alternatively, Contact Us for more information.
We offer a range of shipping options. First, our online service offers competitive shipping rates Australia wide. This includes all states & territories as well as all country and regional areas. Second, we are happy to package orders for pick up. This lets you use your preferred courier. Finally, we are happy to talk about options with you, call us on 0412 836 296 or, alternatively, Contact Us.
We offer local pick up at our Adelaide Trailer Shop locations. Please call us about product availability. We can be called on 0412 836 296 or, alternatively, Contact Us.
Safety is important to us. Please check out our Trailer Safety, Tips & Advice. As well as trailer safety, these pages include tips on towing and installing trailer parts.
It is important to meet regulatory requirements when you work on your trailer. The government sets out help to meet these rules in the Vehicle Standard Bulletin VSB1.
Adelaide Trailer Shop forms part of a broader network of trailer services. This means we offer a complete trailer service. Please see our other helpful trailer services to learn more. These pages provide information about our trailer hire, sales and repairs.
1. Adelaide Trailer Centre?North & South of Adelaide, South Australia
2. Adelaide Trailer Hire?South Australian Local & Interstate Trailer Rental Service.
3. Adelaide Trailer Shop?Quality Trailer Parts & Accessories.
4. Adelaide Trailer Repairs?Trailer & Caravan Servicing & Repairs.
5. SA Custom Trailers?New Custom & Commercial Trailer Sales.
| Weight | 100 kg |
|---|---|
| Dimensions | 250 × 8 × 8 cm |
